Qingdao Huacan Heavy Industry Co.,Ltd.
| Model | ZH550L | ZH660L | ZH760L |
| Max core box size(mm) | 500*500*300 | 600*600*400 | 700*600*500 |
Mold open/close distance(mm) | 300-600 | 350-700 | 400-800 |
Max.shooting sand weight(kg) | 15 | 18 | 25 |
| Single station cycle time(s) | 12 | 15 | 15 |
| Drive mode | Pneumatic /Hydraulic | ||
| Core striped mode | In machine/remove out | remove out | |
| We can design and manufacture according to clients requirements | |||
| Model | ZH890L | ZH1080L | ZH1190L | ZH1290L |
| Max core box size(mm) | 800*900*500 | 1000*800*600 | 1100*900*600 | 1200*900*600 |
Mold open/close distance(mm) | 450-900 | 500-1000 | 550-1000 | 600-1000 |
Max.shooting sand weight(kg) | 40 | 60 | 60 | 60 |
Single station cycle time(s) | 20 | 25 | 30 | 30 |
| Drive mode | Hydraulic | |||
| Core striped mode | remove out | |||
| We can design and manufacture according to clients requirements | ||||
| Model | ZH1290L | ZH1690L | ZH1890L | ZH2090L |
| Max core box size(mm) | 1600*900*600 | 1800*900*600 | 2000*900*700 | 2000*900*950 |
| Mold open/close distance(mm) | 600-1000 | 600-1100 | 950-1100 | 950-1450 |
Max.shooting sand weight(kg) | 80 | 80 | 100 | 230 |
Single station cycle time(s) | 30 | 35 | 35 | 45 |
| Drive mode | Hydraulic | |||
| Core striped mode | remove out | |||
| We can design and manufacture according to clients requirements | ||||
If you have any questions, Please click and contact us.
