Qingdao Huacan Heavy Industry Co.,Ltd.
| Item | Z954 | Z955 | Z956 |
| Core box size(mm) | 450*400*300 | 500*400*300 | 600*400*400 |
| Max.weight of sand shot(kg) | 15 | 15 | 25 |
Template opening and closing dimensions(mm) | Max=500 Min=190 | Max=560 Min=190 | Max=700 Min=330 |
| Max.clamping force of the core box(kg) | 1300 | 1300 | 1300 |
| Productivity(S) | 60 | 60 | 80 |
| Use pressure(Mpa) | 0.65 | 0.65 | 0.65 |
| Shot sand pressure(Mpa) | 0.4 | 0.4 | 0.4 |
| Power(AC) | 380V | 380V | 380V |
| Heating Method | Electric heating | Electric heating | Electric heating |
| Heating Power | 20 | 25 | 30 |
| Sanding Method | Pneumatic delivery / Bucket elevator | ||
| Item | Z957 | Z958 |
| Core box size(mm) | 700*500*400 | 850*500 |
| Max.weight of sand shot(kg) | 30 | 40 |
| Template opening and closing dimensions(mm) | Max=700 Min=330 | Max=840 Min=420 |
| Max.clamping force of the core box(kg) | 1300 | 1300 |
| Productivity(S) | 80 | 80 |
| Use pressure(Mpa) | 0.65 | 0.65 |
| Shot sand pressure(Mpa) | 0.4 | 0.4 |
| Power(AC) | 380V | 380V |
| Heating Method | Electric heating | Electric heating |
| Heating Power | 40 | 50 |
| Sanding Method | Pneumatic delivery / Bucket elevator | |
If you have any questions, Please click and contact us.
