Qingdao Huacan Heavy Industry Co.,Ltd.
| Model | ZH550 | ZH660 | ZH780 |
| Max.core box size(mm) | 500*500*300 | 600*600*400 | 700*800*500 |
| Model open/close distance(mm) | 300-600 | 350-700 | 400-800 |
| Max.shooting sand weight(kg) | 15 | 25 | 40 |
| Single station cycle time(s) | 12 | 15 | 15 |
| Drive mode | Pneumatic | Pneumatic | Pneumatic/Hydraulic |
| Core striped | In machine/remove out | Remove out | |
| we can design and manufacture according to clients requirements. | |||
| Model | ZH890 | ZH1090 | ZH1290 |
| Max.core box size(mm) | 800*900*500 | 1000*900*600 | 1200*900*600 |
| Model open/close distance(mm) | 450-900 | 500-1000 | 550-1100 |
| Max.shooting sand weight(kg) | 50 | 60 | 70 |
| Single station cycle time(s) | 20 | 25 | 30 |
| Drive mode | Hydraulic | Hydraulic | Hydraulic |
| Core striped | Remove out | ||
| we can design and manufacture according to clients requirements. | |||
If you have any questions, Please click and contact us.
