| Parameter | Q698 | Q6912 | Q6915 | Q6920 |
| The effective cleaning width(mm) | 800 | 1200 | 1500 | 2000 |
| The room feed-in size | 1000*400 | 1400*400 | 1700*400 | 2200*400 |
The length of cleaning workpiece(mm) | 1500-12000 | 1500-12000 | 1500-12000 | 1500-12000 |
The thickness of cleaning steel sheet(mm) | 5-60 | 5-60 | 5-60 | 5-60 |
The quantity of shot blasting(kg/min) | 4*180 | 4*250 | 4*250 | 6*250 |
| The first enclosed quantity(kg) | 4000 | 4000 | 4000 | 4500 |
| Parameter | Q6925 | Q6930 | Q6940 |
| The effective cleaning width(mm) | 2500 | 3000 | 4000 |
| The room feed-in size | 2700*400 | 3200*400 | 4200*400 |
| The length of cleaning workpiece(mm) | 1500-12000 | 1500-12000 | 1500-12000 |
| The thickness of cleaning steel sheet(mm) | 5-60 | 5-110 | 5-100 |
| The quantity of shot blasting(kg/min) | 6*250 | 6*360 | 8*360 |
| The first enclosed quantity(kg) | 4500 | 8000 | 11000 |
If you have any questions, Please click and contact us.
